Linha Completa
Ref: LC155Linha completa de PET para Água
Fabricante:
Acmi
Modelo:
Mixed
Ano:
1999
Velocidade:
18000 Garrafas por hora
Produtos:
Água
Recipientes:
PET
Formatos:
0.5 L, 1.0 L, 1.5 L, 2.0 L
Detalhes
Sistema de prevenção de acidentes:
Sim
Manuais:
Sim
Tipo de máquina
Fabricante
Modelo
Ano
Nota
Tipo de máquina
Sopradoras (PET)
Fabricante
Sipa
Modelo
SFR 16
Ano
2004
Tipo de máquina
Monoblocos de Enchimento
Fabricante
Cortellazzi
Modelo
Vega IPS 60-80-10
Ano
1993
Tipo de máquina
Rotuladoras
Fabricante
Krones
Modelo
Cannmatic
Ano
1993
Tipo de máquina
Envolvedora por encolhimento
Fabricante
Zambelli
Modelo
Lft 800/50
Ano
2000
Tipo de máquina
Outros
Fabricante
Acmi
Modelo
Tapes
Ano
2013
Nota
Bottles divider
Descrição
|
MACHINE
|
BRAND
|
MODEL
|
SERIAL NO.
|
YEAR
|
|
Air conveyors for empty bottles
|
VETROMECCANICA
|
EOLO
|
9,1441
|
2004
|
|
OZONIZER
|
AERAQUE
|
OZOMIX 3000
|
517
|
2000
|
|
RINSER
|
SBR
|
NECK RINS 2R 60/122
|
M 182/60
|
1993
|
|
FILLER
|
CORTELLAZZI
|
VEGA
|
VG-166
|
1993
|
|
CAPPER
|
AROL
|
EURO PF
|
2201
|
1993
|
|
FULL BOTTLE CONVEYOR
|
ACMI
|
/
|
/
|
1993
|
|
LABELER
|
KRONES
|
CANNMATIC
|
K073-B81
|
1993
|
|
CIP SYSTEM
|
TEPROM
|
CIPM 1/2
|
1217
|
2000
|
|
BOTTLE DEVIDER
|
ACMI
|
DIVISORE 1/6
|
C/6249
|
|
|
BOTTLE CONVEYOR
|
ACMI
|
/
|
/
|
1993
|
|
HANDLE APPLICATOR
|
COMAG
|
/
|
203
|
Efficiency 75%
Asset Intensity output, with flat water:
Asset Intensity output, with flat water:
18,000 bph with 2.0 L 20,000 bph with all other formats
Line Labor standards (number of operators working on the line and job, operator, checker, loader…) 3 operators
Main observations on safety
All safety interlocks and protection are in place and operational
Line Labor standards (number of operators working on the line and job, operator, checker, loader…) 3 operators
Main observations on safety
All safety interlocks and protection are in place and operational
Oven and the Preform in-feed
Condition of the Following:
Condition of the Following:
- Oven, Turning-over ramps guiding and tension wheel
- Heating modules, Oven ventilation and Cooling shields
- Transfer arms and Cams
- Moulds and Stretching mechanism
- Water and Air CircuitsAll these are in good conditions
Number of SKUs and PET preform weight per SKU
0,5 L: 14 g 1,0 L: 26 g 1,5 L: 26 g 2,0 L: 29-31 g
The existing molds will be supplied along with the machine.
Bottle Design per SKU:
Preform Neck
Alaska 3-start
Electrical cabinet and Command panel
PLC: Siemens S7
PLC: Siemens S7
Overhauling Requirements
The line needs ordinary maintenance only
Filler gaskets, ordinary service
Utilities
LP /HP Compressors.
Original compressors will not be sold with the line.
LP /HP Compressors.
Original compressors will not be sold with the line.
Current chiller serving the blower can be quoted separately.
